Rims: WTB HTZ i30 29" ETRTO 622-30 Inner width: 30mm 6061 series aluminum Asymetric and angled spoke hole drilling distributes spoke tension more evenly Reinforced I-Beam profile Strong sleeved joint Drilled for Presta valve TCS 2.0 Tubeless System compatible Solid Strip included Tubeless valve included 32 holesFront hub: Shimano XT HB-M8110-B Boost 15x110mm (Axle not included) Center Lock (6-Bolt adapter included) Polished angular contact bearings Contact sealed hubRear hubs options: Shimano XT FH-M8010-B (Boost, HG) / FH-M8110-B (Boost, MS) / FH-M8130-B (SuperBoost, MS) Center Lock (6-Bolt adapter included) Quick Engagement Freehub, 36 Points, 10 deg. engagement HG compatible Shimano 11spd and Sram NX / SX splined 12spd (10spd and below needs spacer) MS compatible 12 Spd Shimano Micro Spline onlyAssembled in North America by experienced wheelbuilders with Sapim Race spokes (Black), Brass Polyax Nipples (Black)
| Axle Type |
12mm TA |
| Freehub Body |
Shimano HG |
| Hub Model |
Shimano XT FH-M8010-B |
| Hub Spacing |
148mm |
| Position |
Rear |
| Rim Color |
Black |
| Rim Construction |
Double wall Sleeved |
| Depth |
19mm |
| Rim Drilling |
F: 21 R: 24 |
| Rim External Width |
34mm |
| Rim Internal Width |
30mm |
| Rim Material |
Aluminum |
| Rim Model |
WTB HTZ i30 |
| Skewers Included |
No |
| Spoke Type |
Sapim Race |
| Valve |
Presta |
| Wheel-Brake Comp. |
Disc Center Lock / IS 6-Bolt |
| Wheel Diameter/ISO |
29 / 622 |
| Wheel Tire Type |
Tubeless Compatible |
| Rim inner width range |
28-34.9mm |
