The Mountain Bikers eMTB
Living in uncharted territory, the Relay is a lightweight, long travel, modular mountain bike.
We have always wanted a bike that could provide both an electric and non-electric experience in one chassis. The Relay is light, efficient, and quiet. This provides a more intuitive and natural feel on trail than many would expect from an eMTB. The Relay is here and ready to meet all of your mountain biking needs. Going for a rip with friends on eMTB's? Power it up and head out. Going for a rip with some friends on mountain bikes? Simply remove the battery and hit the trail with no tools required. The Relay does it all.
Specs:
| FRAME | Relay Carbon 160mm |
| WHEEL SIZE | 29" (X-Small 27.5") |
| DRIVE UNIT | Fazua Ride 60 |
| BATTERY | Fazua Energy 430 Take Out |
| DISPLAY | Fazua Top Tube LED Hub |
| ASSIST SWITCH | Fazua Ring Control |
| REAR SHOCK | RockShox Super Deluxe Select+ |
| (205x60mm) | |
| FORK | RockShox Lyrik Select+ |
| (160mm) | |
| HEADSET | FSA No.55R |
| STEM | ANVL Swage (40mm) |
| HANDLEBAR | ANVL Mandrel Alloy 35 |
| XS/SM (800x20mm) | |
| MD/LG(800x30mm) | |
| XL/XXL (800x40mm) | |
| GRIPS | ODI Elite Flow Lock-On |
| SADDLE | SDG Bel Air 3 LUX |
| SEATPOST | OneUp Dropper Post |
| XS (120mm) | |
| SM (150mm) | |
| MD (190mm) | |
| LG (210mm) | |
| XL/XXL (240mm) | |
| BRAKES | SRAM Maven Bronze |
| ROTORS | SRAM Centerline (200mm) |
| SHIFTER | SRAM Eagle 90 MMX Single Click |
| DERAILLEUR | SRAM Eagle 90 |
| CASSETTE | SRAM XS 1275 (10-52t) |
| CHAIN | SRAM GX Eagle Transmission |
| CRANK | RaceFace Aeffect ETOR |
| (165mm, X-Small 160mm) | |
| CHAINRING | SRAM XX Direct Mount (32t) |
| RIMS | DT Swiss E 1900 Spline 30 |
| SPOKES | DT Swiss Champion |
| HUBS | DT Swiss 370 Ratchet LN |
| TIRE/FRONT | Maxxis Assegai 3C EXO+ (2.5) |
| TIRE/REAR | Maxxis Minion DHRII 3C EXO+ (2.4) |
| INCLUDED | Fazua Charger |
| Tubeless Valves & Sealant | |
| COLOR OPTIONS | Nightshadow |
| Sea Salt |
