Frame
Scale 24 Disc Junior
Alloy 6061 / Semi int. HT
SCOTT dropout / IS
Alloy 6061 / Semi int. HT
SCOTT dropout / IS
Fork
SR Suntour XCT-JR 24 Disc
50mm travel
Softer spring setup
50mm travel
Softer spring setup
Rear Derailleur
Shifters
Shimano SL-RS45-8R
Revo Shifter
Revo Shifter
Crankset
Prowheel / Alloy Crank 140mm
32T / w/CG PVG double cover
32T / w/CG PVG double cover
BB-Set
Feimin / BB68 / cartridge / square taper
Chain
KMC Z8.3
Cassette
SunRace CSM55
8 Speed / 11-34T
8 Speed / 11-34T
Brake Levers
Tektro TS325A
Brakes
Tektro SCM-02
Mech. Disc Brake / 160mm rotor
Mech. Disc Brake / 160mm rotor
Handlebar
Junior Flat-Bar / Alloy
560mm / Syncros Youth 100/80 Grip
560mm / Syncros Youth 100/80 Grip
H'stem
LEADTEC LCS-7130
50mm / 25.4mm clamp
50mm / 25.4mm clamp
Seatpost
Alloy / 26.8mm / 300mm
Seat
Syncros Youth
Headset
Feimin FP-H807, 1 1/8" Semi Int.
Hub (Front)
Formula DC-19-F / QR
Hub (Rear)
Formula DC-25-7-R / QR
Spokes
15G / UCP / black
Rims
Alex C-1000 Disc
Front Tire
Kenda K1227 Booster / 24x2.2" / 30TPI
Rear Tire
Kenda K1227 Booster / 24x2.2" / 30TPI
Pedals
MARWI SP-700 / w/Reflector
Extras
Kickstand
Accessories
Syncros Stem Protector
