The Fluid FS 2 24 features progressive handling, low standover, youth-tuned suspension and a dropper that is optimized for 9-12 year old riders below 90 pounds.
| FRAME |
6061 Alloy Frame, 120mm Travel, Tapered Head Tube, ISCG05 Mount |
| FORK |
Manitou Machete J-Unit Comp 24", 145mm Travel |
| REAR SHOCK |
X-Fusion 02 Pro R, 170x35mm |
| REAR SHIFTER |
Box Four Multi |
| REAR DERAILLEUR |
Box Four Wide |
| CRANKSET |
Alloy Two Piece, 28T Narrow Wide, 140mm |
| BOTTOM BRACKET |
BSA Threaded |
| CASSETTE |
Box Four, 11-42T, 8 Speed |
| CHAIN |
Box Four 8 Spd Chain |
| FRONT BRAKE |
Tektro HD-J285 Hydraulic, Organic Pads |
| FRONT BRAKE ROTOR |
Tektro 160mm |
| REAR BRAKE |
Tektro HD-J285 Hydraulic, Organic Pads |
| REAR BRAKE ROTOR |
Tektro 160mm |
| BRAKE LEVERS |
Tektro 2-Finger Jr. |
| HANDLEBAR |
6061 Aluminum, 660mm, 15mm Rise |
| STEM |
6061 Alloy, 35mm Length, 31.8mm Clamp |
| SEATPOST |
TranzX YSP18B, 31.6mm, 100mm, Kid's Tune |
| HEADSET |
Sealed Cartridge Bearing, Tapered |
| SADDLE |
Norco Youth |
| GRIPS |
Jr. Lock-On |
| PEDALS |
VP-225 Jr. Flat |
| FRONT HUB |
Bear Pawls 15x110mm Boost, 32H, 6 Bolt |
| REAR HUB |
Bear Pawls 12x148 Boost, 32H, HG, 6 Bolt |
| RIMS |
Stan's Flow K 24", 32H |
| FRONT TIRE |
Maxxis Minion DHF EXO/TR 2.4" |
| REAR TIRE |
Maxxis Minion DHR II EXO/TR 2.3" |
| REAR HUB SKEWER |
- |
| SPOKES/NIPPLES |
Stainless, Black |
