The Ripmo isn't just a bike; it's a legend.
With multiple "Best in Test" awards and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail-slaying machine. How do you improve on that?
The new Ripmo is loaded with new features: internal downtube storage, a flip chip for mixed wheels, a slacker head angle, and increased coil compatibility. We've also expanded our sizing options and added size-specific details—right down to the bottom bracket height.
Every rider deserves the same great ride feel, no matter their height or proportions. We use size specific seat tube angles and suspension kinematics to bring incredible balance and speed to all size riders. Even chainstay length and bottom bracket height are tailored to each frame size.
We've added a third size in the middle of the bell curve to provide a fit that’s just right. With 80% of our riders falling between 5’5” and 6’0”, we introduced a new "Extra-Medium" size. The extra-medium (size 3) now sits in the middle of our size range, while our size five remains the traditional XL.
We’ve added more adjustability with a new flip chip - now you can run 29” or 27.5”/29” mixed (MX) wheels on all sizes without compromising the geometry. The Extra Medium and larger sizes ship with 29” wheels, while the Small and Medium sizes come with MX wheels.
We continue to use the critically acclaimed dw-link suspension platform known for its efficient climbing and strong downhill performance; it sets the standard for modern mountain bikes.
Drawing on the race-proven HD6 design, the Ripmo now has a coil spring friendly progressive shock rate and shorter clevis which makes it compatible with pretty much any coil shock.
Our size-specific kinematics make sure every size bike pedals amazing while still keeping things quiet and calm on challenging trails.
Get that gear off your back and into your bike with our frame storage system. The latch operates effortlessly, even in cold, muddy conditions while wearing gloves. The door is water-resistant, rattle-free, and robust.
We’ve partnered with Cotopaxi to craft a set of two internal bags for your snacks, tools, or whatever. Cotopaxi is known for high-quality construction and sustainable practices; the bags are crafted from remnants and dead stock, making each bag colorful and unique.
If it's our fault, we'll fix it. Simple as that.
Progressive Geometry
Enhanced bike handling capabilities over rough and steep terrain.
| 160mm Fork (575mm axle to crown) | ||||||
| Nominal Size | SM | MD | XM | LG | XL | |
| Seat Tube | A | 395 | 400 | 415 | 457 | 477 |
| Top Tube | B | 578 | 605 | 630 | 655 | 685 |
| Head Tube | C | 85 | 95 | 110 | 125 | 140 |
| Chainstay 29" | D | 435 | 435 | 436 | 438 | 440 |
| Chainstay MX | D | 432 | 432 | 433 | 435 | 437 |
| Seat Tube Angle | E | 77° | 76.5° | 76.5° | 77° | 77.5° |
| Saddle Height for Seat Tube Angle | F | 650 | 700 | 745 | 790 | 830 |
| Head Tube Angle | G | 64.5° | 64.5° | 64.5° | 64.5° | 64.5° |
| Wheelbase | H | 1195 | 1219 | 1249 | 1286 | 1329 |
| Stack | I | 616 | 622 | 633 | 643 | 654 |
| Reach | J | 436 | 456 | 478 | 506 | 540 |
| BB Drop 29" | K | 36 | 33 | 30 | 27 | 24 |
| BB Height* | 338 | 341 | 344 | 349 | 350 | |
| Standover | L | 693 | 734 | 757 | 772 | 784 |
| Recommended Seatpost Drop | 140 | 170 | 185 | 213 | 213 | |
| Crank Length | 165 | 165 | 170 | 170 | 170 | |
| Tire Size | 2.35-2.5" | 2.35-2.5" | 2.35-2.5" | 2.35-2.5" | 2.35-2.5" | |
| Water Bottle Size | 1 x 22oz | 1 x 26oz | 1 x 26oz | 1 x 26oz | 1 x 26oz | |
Sizing
Specifications
| Wheels | Blackbird Send Alloy, 32 Hole, Ibis Logo Hubs |
| S–M, F: Send I 29" R: Send II 27.5" | |
| XM–XL, F: Send I 29" R: Send II 29" | |
| Front Tire | Maxxis Assegai 29x2.5 EXO+ |
| Rear Tire | Maxxis DHR II, EXO+ |
| S–M: 27.5" x 2.5", XM–XL: 29" x 2.5" | |
| Brakes | SRAM Maven |
| Rotors (F/R) | SRAM Centerline 200/180 |
| Crankset | SRAM Eagle 90 Transmission DUB, 30t Alloy Ring |
| S-M: 165mm, XM-XL: 170mm | |
| Bottom Bracket | SRAM DUB BSA |
| Rear Derailleur | SRAM Eagle 90 Transmission |
| Shifter | SRAM Eagle 90 Transmission Shifter |
| Cassette | SRAM XS 1275 Eagle Transmission 10-52 |
| Chain | SRAM GX Eagle Transmission |
| Headset | Cane Creek 40 ZS44/ZS56 |
| Grips | Lizard Skins Single Clamp |
| Handlebar | Blackbird 35 Aluminum Riser Bar 800mm |
| Stem | BLKBRD 35 Stem |
| S–M: 35mm, XM–XL: 50mm | |
| Seatpost | KS Vantage Dropper |
| S: 110-140mm, M-XM:140-170mm, L-XL: 180-210mm | |
| Saddle | WTB Silverado Fusion CrMo 142 |
