This One Goes to 11!
Head to the race track, stack up shuttle laps, or hit the bike park on the TR11.
The TR11's DNA blends a healthy strain of DH speed, bike park party laps, and freeride grit. It will help you live all your gravity-fed dreams with the confidence of a 29" wheel up front while maintaining flickability on jumps or tight corners with a 27.5" wheel out back. This bike was designed to let you party on the trails rather than worry about the small details. The TR11 frame is built tough, so you can throw it in the truck or blast through a rock garden without hesitation. With two build specs featuring powerful Maven brakes and RockShox suspension, no trail is too rough or too steep for anything you want to throw at it. With adjustable geometry at the headtube and chainstay, the TR11 will quickly take you to the next level. This one goes one louder!
Build Specifications
| PRICE | $6,499 USD |
| FRAME | TR11 Alloy 200mm |
| WHEEL SIZE | Mixed |
| REAR SHOCK | RockShox Vivid Coil Ultimate DH |
| (250x75mm) | |
| SM (350 lb) | |
| MD (400 lb) | |
| LG (450 lb) | |
| XL (500 lb) | |
| FORK | RockShox Boxxer Ultimate |
| (200mm) | |
| HEADSET | TR11 Reach Adjust |
| STEM | OneUp Components Direct Mount (45mm) |
| HANDLEBAR | OneUp Components Alloy |
| SM (800x20mm) | |
| MD/LG/XL (800x35mm) | |
| GRIPS | ODI Elite Flow Lock-On |
| SADDLE | SDG I-Fly Transition Team Edition |
| SEATPOST | SDG I-Beam |
| BRAKES | SRAM Maven Silver |
| ROTORS | SRAM HS2 (200mm) |
| SHIFTER | SRAM XO1 DH 7sp |
| DERAILLEUR | SRAM XO1 DH Medium Cage |
| CASSETTE | SRAM XG 795 (10-24t) |
| CHAIN | SRAM PC 1130 |
| CRANK | SRAM XO1 DH DUB |
| (34t/165mm) | |
| CHAINGUIDE | OneUp Bash Guide |
| RIMS | Crankbrothers Synthesis Downhill Alloy |
| SPOKES | Sapim D-Light (Front) |
| Sapim Race (Rear) | |
| HUBS | Crankbrothers Ratchet |
| TIRE/FRONT | Maxxis Highroller III 3C DH (2.5) |
| TIRE/REAR | Maxxis Highroller III 3C DH (2.5) |
| INCLUDED | Tubeless Valves & Sealant |
Frame Specifications
| REAR TRAVEL: | 200mm |
| FRONT TRAVEL: | 200-203mm |
| WHEEL SIZE: | 29" Front / 27.5" Rear |
| SIZES: | SM, MD, LG, XL |
| FRAME BEARINGS: | 2x 6903, 4x 6902, 4x 6802 |
| FORK AXLE TO CROWN: | 606mm (Includes Headset) |
| FORK OFFSET: | 46-48mm |
| REAR SHOCK SIZE: | 250mm x 75mm |
| Frame sizes small and medium are not compatible with the Fox Float X2 shock | |
| SHOCK HARDWARE: | 25mm x 8mm Top and Bottom |
| HEADSET (TOP): | 56mm Zero Stack |
| HEADSET (BOTTOM): | 56mm Zero Stack |
| BB SHELL: | 83mm BSA Threaded |
| CHAINLINE: | 56.5mm |
| REAR BRAKE MOUNT: | 200mm Post Mount, 223 Max Rotor Size |
| REAR DERAILLEUR HANGER: | Transition TR11-HG |
| REAR AXLE: | Transition Axle For UDH, 12mm x 148mm Spacing |
| ISCG TABS: | ISCG05 |
| SEATPOST DIAMETER: | 31.6mm |
| SEAT CLAMP: | 37mm |
| MAX SEATPOST INSERTION: | 115mm |
| MAX CHAINRING SIZE: | 38T Single Ring |
| REAR MAX TIRE SIZE: | 27.5 x 2.5 (*see FAQ) |
| REAR SHOCK SAG: | 19-25mm (25-33%) |
